LDI Laser Diode Illuminator

• Configured for 7 wavelengths
• Up to 1W of power per channel
• Feedback controlled stability
• Integral laser despeckling

Product Description

Designed and manufactured by our US distributors 89 North, the LDI is a multiline, solid-state laser illuminator offering up to 1000mW of output power via a multimode fiber at the price of lower power LED light engines. With feedback controlled output stability and up to a 100:1 linear dynamic range, the LDI is the ideal light source for a wide range of applications including spinning disk confocal microscopy, structured illumination microscopy, FRAP, photoactivation/photoconversion, and PALM/STORM.

Download Data Sheet Manuals video support Get a Quote Back to Lasers

Additional information

Appplications

• Spinning Disk Confocal Microscopy with Crest X-Light V2
• Super Resolution SIM Imaging with Crest VCS
• Optogenetics with DLPs or Multiport Illuminator
• Photoactivation/Photoconversion with SLM or Multiport Illuminator
• FRAP with SLM or Multiport Illuminator
High output power

• Shorter exposures
• Faster Imaging
• Faster activation times in optogenetics and photoactivation experiments
• Faster bleaching times in FRAP experiments
Feedback controlled optical stability

• Quantitative imaging, ideally suited for ratiometric imaging
• More repeatable optogenetics experiments
Up to 100:1 linear dynamic range

• Ability to turn power down when needed and maintain stability and quantitative imaging
Configured for 7 lines

• Covers most of the standard fluorescence probes
No user alignment

• Easy to use and maintain
Accessories

• TTL / analogue breakout interface available

Laser Lines Available

Laser Line (nm)
405
445
470
520
528
555
640
Power (mW)
*Out of fibre (400 μm 0.22 NA)
300
1000
1000
500
500
1000
500

LDI Preliminary Specifications
